TLU-015

Description: Output led the red led indicates the output status. Ready led during functioning, the green led permanently on indicates a normal operating condition;
fast blinking indicates an output overload condition. See the "setting" paragraph for setup procedure indications. Mark / bkgd  pushbutton the pushbutton activates the setup procedure. connections + 10 to 30 vdc remote a * brown red orange grey remote b * analog output white blue npn/pnp 0 v shield ** * = connect the unused remote wires to 0 v. ** = the cable shield is insulated from the sensor housing; it is recommended to connect the shield to 0 v. M12 connector 10 to 30 vdc - + 0 v npn/pnp analog output (white) (brown) (blue)(black)

Click here to download catalogue PDF
