Voxintech VXT-JB-M12-04D-02M
Description: VXT-JB-M12-04D-02M M12 passive sensor distribution box, 4-port. 4 x M12x1 female sockets, A-coded, 5-pin, nickel-plated brass threads. Dual channel = 2 independent signals per port (8 signals total) on one 2 m moulded homerun cable (11-core). Each port also accepts a single-signal 3-wire sensor on one channel, so this box replaces both single-channel and dual-channel distribution boxes of the same port count. Output: PNP (sourcing), 24 V DC nominal (10-30 V DC), approx. 2 A per channel / 4 A per port / 8 A per box. Fully epoxy-resin potted body with gold-plated contacts - no screw terminals to loosen under vibration. 1 green power LED + 1 yellow signal LED per channel for at-machine diagnostics. IP67 sealed with all ports mated or capped; high-heat and high-vibration rated. Pinout 1:+24V, 2:signal B, 3:0V, 4:signal A, 5:PE - accepts any brand of M12 cordset (4-pin plugs mate too). HSN 8536 90 90. Applications: compact SPMs, single-station assembly cells, one filling/capping head, small pneumatic panels.
Equivalent Models for This Model:
- DUAL-CHANNEL (2-signal) — direct equivalent:
Autonics PT4-4DP5-5 (nearest; 5 m) (verify 2-signal variant) · Phoenix Contact SACB-4/8-L (verify) · Murrelektronik Exact12 4xM12 5-pole (verify) · Lapp AB-B4-M12-4 (verify). - SINGLE-CHANNEL (1-signal) — also replaced (VXT uses one channel per port):
Autonics PT4-3DP / PT4-2D (4-pin) · Phoenix Contact SACB-4/4-L (verify) · Lumberg ASBS 4/LED 5-4 (verify).
